6-1 Specifications
Design and specifications are subject to change without prior notice.
Class B (Information Communication equipment for residential use)
This device is registered for EMC requirements for home use (Class B). It can be used in all areas. (Class B equipment
emits less electromagnetic waves than Class A equipment.)
MODEL NAME TC180
LCD Panel Size 18.5 inches (47 cm)
Display area 409.8 mm (H) x 230.4 mm (V) / 16.13 inches (H) x 9.07 inches (V)
Pixel Pitch 0.300 mm (H) x 0.300 mm (V) / 0.012 inches (H) x 0.012 inches (V)
Synchronization Horizontal 31 ~ 60 kHz
Vertical 56 ~ 75 Hz
Display Color 16.7 M
Resolution Optimum resolution 1366 x 768 @ 60 Hz
Maximum resolution 1366 x 768 @ 60 Hz
Input Signal, Terminated
RGB Analog
0.7 Vp-p ± 5 %
Separate H/V sync, Composite
TTL Level (V high ≥ 2.0 V, V low ≤ 0.8 V)
Maximum Pixel Clock 85.5 MHz (Analog / Digital)
Power Supply This product supports 100 – 240 V. Since the standard voltage may differ from
country to country, please check the label on the back of the product
Signal connectors
15pin-to-15pin D-sub cable, Detachable
Dimensions (WxHxD) / Weight 443.4 x 334.8 x 197.0 mm (17.46 x 13.18 x 7.76 inches) / 5.1 Kg (11.24 Ibs)
VESA Mounting Interface 100
mm
x 100
mm /
3.94
inches
x 3.94
inches
Environmental
considerations
Operating Temperature : 50 °F ~ 104 °F (10 °C ~ 40 °C)
Humidity :10 % ~ 80 %, non-condensing
Storage Temperature : -4 °F ~ 113 °F (-20 °C ~ 45 °C)
Humidity : 5 % ~ 95 %, non-condensing
