4-1-8. No Video (Component)
Symptom Audio is normal but no picture is displayed on the screen. -
Major
checkpoints
Check the Component source -
Check the Main Chipset. -
This may happen when the LVDS cable connecting the Main Board and the Panel is disconnected. -
Diagnostics
Does the component data appear at
TP-COMP_Y, COMP_PB, COMP_PR
(Comp / Y, Pb, Pr) ?
Does the digital data appear at
TP - O_TXCLK+, O_TXCLK- ?
Yes
Yes
Yes
Yes
Check a set in the 'Stand-by mode'
Input the component source properly.
Please, Contact Tech support.
Check CN802.
Change the Main Assy.
Check IC1102 (SX1).
Change the Main Assy.
No
No
No
No
No
Power indicator LED is off.
Lamp(Backlight) on, no video ?
Check the component source and
check the connection of component
cables(Y,Pb,Pr)?
Check the LVDS cable?
Check the T-Con B'd?
Replace the LCD panel?
5
2
Caution Make sure to disconnect the power before working on the IP board.
