6-4
6. Wiring Diagram
CN1001 (HDMI1)
1 HDMI1_RX2+ 11 GND
2 GND 12 HDMI1_RXCLK-
3 HDMI1_RX2- 13 HDMI_CEC
4 HDMI1_RX1+ 14 GND
5 GND 15 SCL
6 HDMI1_RX1- 16 SDA
7 HDMI1_RX0+ 17 GND
8 GND 18 5V
9 HDMI1_RX0- 19 HPD
10 HDMI1_RXCLK+
CN1002_H2 (HDMI2)
1 HDMI2_RX2+ 11 GND
2 GND 12 HDMI2_RXCLK-
3 HDMI2_RX2- 13 HDMI_CEC
4 HDMI2_RX1+ 14 GND
5 GND 15 SCL
6 HDMI2_RX1- 16 SDA
7 HDMI2_RX0+ 17 GND
8 GND 18 5V
9 HDMI2_RX0- 19 HPD
10 HDMI2_RXCLK+
OP1301 (SPDIF)
1 SPDIF_OUT 3 GND
2 B5V
CN1301 (HEADPHONE)
1 GND 4 GND
2 HP_SL 5 HP_IDENT
3 HP_SR 6 NC
CN1302 (SPEAKER)
1 R+ 3 L+
2 R- 4 L-
