Part’s List
No.
1
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
Description
PLATE-CONTROL OUT
C-OIL (CAPACITOR)
CLIP-CAPACITOR
SCREW-TAPPING
C-OIL(CAPACITOR)
TERMINAL-BLOCK
HOLDER PCB
HOLDER-WIRE
SCREW-TATITE
SCREW-TAPPING
SCREW-SPECIAL
ASS’Y-LEAD, WIRE
SPRING-O.L.P
O.L.P
LEAD-WIRE C
SCREW-TAPPING
LABEL-CAUTION
THERMOSTAT
CONNECT-WIRE
CONNECT-WIRE
SCREW-TAPPING
TRANS
CONNECT-WIRE
ASS’Y THERMISTOR
SCREW-TAPPING
HOLDER WIRE
CLAMP WIRE
CABEL-CLAMP
ASS’Y PCB MAIN OUT
Specification
SGCC-M T0.6
35uF/450VAC
SGCC-MØ50
2S-M4 x L10
1.5uF/450VAC
300V, 20A 5P
ABS, BLK
NYLON(BLK)
FH, M4 x L12
TH, M4 x L16, ZPC(YEL)
M4 x 8
ASS’Y
STS304-WPA
RAC12074-9622
SILICON GLASS
PH, M4 x 25
50 x 12
PW-2N, ON/OFF:4/15
WIRE ASS’Y
WIRE
PH, 2S, M3 x 8
-
ASS’Y
AWH126JE
TH, +, 2S, M3 x 8
SGCC-M+PVC COATING
DAWH-5NB
NYLON 66 / 3N
ASS’Y
-
-
-
SNA
-
-
-
-
SNA
SNA
SNA
-
-
-
-
SNA
SNA
-
-
-
SNA
-
-
-
SNA
-
-
-
-
Remark
4 Assembly control out (cont’d)
Assembly drawing and part’s list (cont’d)
