To Next PageTo Next PageHow to check drain in Samsung wa48h7400aw Washer?
To check the drain in your Samsung washer, examine the draining pump motor for any foreign objects. Inspect the natural drain for blockages as well. Also, verify all connections and wires are correctly connected and not broken. If the washer malfunctions when the water temperature is high, the pump may need replacing. If the motor stops due to frozen water, remove the ice.
What to do if Samsung wa48h7400aw Washer has door check problem?
If your Samsung washer has a door check problem, the main PBA door detection circuit might be defective, requiring replacement.
What to do if my Samsung Washer has water supply problems?
If your Samsung washer isn't getting water, several things could be the cause. First, the water supply valve may be broken and needs replacement. Also, the water supply could be blocked by a foreign object in the valve, or the water might be frozen. Finally, a malfunctioning PBA relay could also be the issue, requiring PBA replacement. Check these components and take appropriate action.
What to do if my Samsung wa48h7400aw has communication issues?
If your Samsung washer is experiencing communication issues, start by checking the wire connections and terminal contacts between the sub and main PBAs. Look for any disconnected wires. Also, check if the sub PBA is short-circuited due to moisture. If the main PBA’s communication circuit is faulty, it may need to be replaced.
How to check motor driving and hall sensor on Samsung wa48h7400aw?
To check the motor driving and hall sensor on your Samsung washer, inspect the motor connector terminal connections. Verify the motor cover is not damaged. Check the coil for breaks due to moisture or foreign substances. If the PBA control circuit is defective, the PBA may need replacement.
How to check temperature sensor in Samsung wa48h7400aw?
To check the temperature sensor in your Samsung washer, first check the connections for the washing heater temperature sensor connector. If the washing heater temperature sensor has a functional error, replace it. Check the connections for the dry heater temperature sensor connector. If the dry heater temperature sensor has a functional check, replace it.
How to troubleshoot water level sensor on Samsung Washer?
To troubleshoot the water level sensor on your Samsung washer, begin by checking the water level sensor terminal connections. Ensure the correct part code for the water level sensor is used, as an incorrect part can cause abnormal operation. If the water level sensor is defective, replace it. If these steps don't resolve the issue, consider replacing the PBA.
General| Style | Top-Loading |
|---|---|
| Color | Silver |
| Washer Capacity | 4.5 cu ft |
| Dryer Capactity | - |
| Max Spin Speed | 1100 RPM |
| Spin Speeds | - |
| Spin Class | C |
| Number of Cycles | 11 |
| Cycle Selections | Whites |
| Wash | PureCycle |
| Options | extra rinse cycles |
| No spin and No heat | Delay End – Up to 19 |
| Hours | Extended Spin |
| Noise level | - |
| Temperature Selections | 6 (Cold/20/30/40/60/95) |
| Energy Class | - |
| Annual Energy Consumption | 145 kWh |
| Annual Water Consumption | - |
| Water Consumption Per Cycle | - |
| Voltage | 120 V |
| Frequency | - |
| Current | 15 A |
Weight and Dimensions| Depth | 29 1/4 in |
|---|---|
| Height | 43 7/8 in |
| Width | 27 in |
| Net Weight | - |
Instructions for service engineers to ensure safe operation and prevent accidents during servicing.
Details the various features of the washing machine.
Lists the technical specifications of the washing machine, including dimensions and capacity.
Provides a detailed comparison of features between different model grades.
Lists optional items and their specifications, including part codes.
Lists the necessary tools required for disassembling and reassembling the washing machine.
Provides step-by-step visual guides for disassembling the control panel and PCB assembly.
Details information modes for diagnosing washer issues, including check types and causes.
Provides countermeasures and troubleshooting procedures for specific check codes related to washer malfunctions.
Explains how to properly level the washing machine using its legs and additional supports.
Displays a schematic diagram of the main printed circuit board (PCB) with component locations.
Details the connectors and terminal parts on the main PCB, listing their functions.
Shows the layout and components of the sub printed circuit board (PCB).
Details the connector terminal parts of the sub PCB, listing functions and pin assignments.
Presents the schematic wiring diagram of the washing machine, including color codes.
Explains the naming convention used for washing machine model numbers.
