Part Figure Description
Disassembling
and Repairing
the DRUM
1. Separate the ASSY DRUM from TUB, remove the M10
bolt from the upper ASSY DRUM, disassemble the
ASSY FLANGE SHAFT.
2. Remove the screws from the outer sides and then
remove the two upper and lower BALL BALANCERS.
3. Remove the screws from the outer sides and then
remove the 3 DRUM-LIFTERS.
7.Disassembly & Reassembly
71
