Samwha DSP DSP-VIP-PL - Electrical Standards and Communication

*110VAC:75∼150VAC,50/60Hz(110∼220
VDC)/Optional
Max Conductor Size
25sq
Screw Torque
Max 0.6 N.m
Insulation Resistence/IEC-60255-5
10Mohm or more/500VDC,circuit-case
High Voltage Withstand Test/
IEC-60255-5
*circuit-case:AC 2000V,60Hz, 1 min
*contact-contact:AC 1500V,60Hz,1 min
Lightning Impulse Voltage Withstand
Test)/ IEC-60255-5
*Circuit-Ground,Circuit-Circuit:1.2/50uS,5KV
*Control Circuits:1.2/50uS, 3KV
1 MHz Burst Immunity Test: IEC- 60255
-
22-1
2.5KV,Positive/Negative under
2sec
Electrostatic Discharge:IEC-60255-22-2
Air:Level 3, 8KV,Contact:Level 3,6KV
Radiated Electromagnetic Field
Disturbance:IEC-60255-22-3
Level 3, 10V/m
Electric Fast Transient Burst:IEC-60255-
22-4
Power,Realy output:Level 4,4KV
Surge Immunity test:IEC- 60255-22-5
Relay output:1.2X50uS,2KV(0
O
,90
O
,180
O
,270O)
Conducted Disturbence Test:
IEC-60255-22-6
10V,Level 3
Digital
Communication with
communication
module/recorder
Physical feature
*RS 485/ RS 422 : CM-44
8*RS485 : MWR-S
Address
1 ~ 250
Speed
*MWR-S:9.6/19.2/38.4/57.6/76.8/115.2kbps
*CM44: 9.6/19.2/38.4kbps
wiring
connection
*Input/Output:RJ 45 ot Screw Terminal
*RJ45 and Screw Terminal(5P) is commoned
Physically
*RJ45 is recommended for the test by "Samdsp"
Termination
resistence
*DIP S/W selection / 200 Ohm
Cable
Sheathed cable,2 Pair
Current Loop Communication:4 ~
20mA
Maximum value in 3 phase current
Consuming power
10W max
7. Protection List
Item Description Remarks
Over Voltage
*110V:110~150
*220V:220~290
*380V:380~450
*440V:440~510
*480V:480~550
*The 3 phase voltage over upper level of
each range makes trip by over voltage.
*The trip caused by a voltage is reset
automatically after reaching over preset
value
*Only 110V is based on a secondary
voltage of PT
*If line voltage is under preset value in
initial starting state,motor can not start.
