Samwha DSP DSP-VIP-PL - 13-3.Cab Mode Calibration

13-3.Cab Mode
This mode is appeared as pressing "SET" key for 5 sec or more and is disappeared as pressing
"SET" key shortly once more, also it is not recommened that user makes a calibration without
checking by accurate source
ㅋ
Function/range
Description
Factory setting
value
P0000
Password Input
*need to input factory value "0000" to enter
into this mode group
*to calibrate slight difference between
indication and actual value within +,-12.7%
*next mode by pressing right direction key
"CLR"
0000
CrPEr
to have a
caribration for
phase "R" current
*possible to adjust within +, - 12.7% from
indicated value by using "UP" or "DN" key
0
CsPEr
to have a
caribration for
phase "S" current
0
CtPEr
to have a
caribration for
phase "T" current
0
vrPEr
to have a
caribration for
phase "R" voltage
0
vsPEr
to have a
caribration for
phase "S" voltage
0
vtPEr
to have a
caribration for
phase "T" voltage
0
EcPEr
to have a
caribration for
ground fault current
tEPEr
to have a
caribration for
temperature
tranS/OFF/
d-Ear
to select indication
pattern of
incomming voltage
*OFF: to indicate line voltage:v1,v2,v3
*d-Ear:to indicate average voltage
OFF
PEdIt/setting
Value(P****)
to change password
*possible to enter new digit by using "UP" or
"DN" key after positioning a curser on the
required digit
*possible to enter into main mode or sub
mode as pressing "mode" key
vUb/OFF/
setting value
to preset voltage
unbalance
protection rate(%)
*trip in case preset rate condition is kept on
preset time or more
*rate:[(Max V-Min V)/Max V]*100 [%]
*adjustable range:2%~40%
OFF
v-uT/
setting value
to preset operating
trip delay time for
voltage unbalance
*to preset a operating trip time for voltage
unbalance
*Adjustable range: 0.5~10 sec
3
