times of auto reset
*the preset time is counted from the
instant of first trip and return to the
preset condition for auto reset after the
allowable time is elapsed
*Password lock in Auto Reset
:able in case the preset number of auto
trip is done within preset total reset
time
:otherwise, the counted number of trip
time is initialized to previous preset
value
*If Hr is preset in "rESEt" mode, this
mode becomes disable
trIP /8 ~1/trip
cause / trip
value
to show latest
number of 8 tripped
cause
*To show latest number of 8 trip cause in
order
*8th tripped cause and caused value are
appeared firstly, next 7th and finally 1st
trip ped cause as every pressing "up"
button
*to support an operator how many order of
8 trip event is appeared, a number of
lighted LED in bar graph is in conjunction
with it.
*need to press "Mode" key to return to
main mode
*trip information in order:faulty phase and
faulty value is appeared alternatively
*more detailed information can be
retrieved by note PC directly or remote
center
trip
Addr /Setting
value
to put self-address to
communicate with pc
*to preset an address for 485/422
communication
*range of number:#1 ~ #250
1
bPS / setting
value
to decide
communication
speed
*to select communication speed :
9.6/19.2/38.4/57.6/76.8/115.2kbps
115.2
Tover/OFF/S
etting
value(SDDT
-DODT)
Main contactor Auto
Close
*In case a line power is "on" again within a
preset time(SDDT) after a line power is
"OFF" during a normal operation,
main contactor(M) is closed
automatically
after another preset time(DOMT)
*Shut Down Delay Time:1~5sec/Adjustable
*Delay On Make Time:0(instant)~25sec
/Adjustable by 5sec unit
*Expression in mode:eg/2-3:in case power
is
on within 2sec after power-off,motor
starts
After 15sec((3 is matched with 15sec) from
the instant of power-on
*If Y-D starting was done, main
contact(M) and D contact is applied
together.
OFF
