Cn/fixed
value
to count tripped
number of main
contactor
*Fixed Value:to show accumulated number
of actual trip
* max value is 65535
*To clear:press "UP" firstly-->keeping
pressed "UP" -->nextly,press "DN"
key ,then keep 1 sec under pressed state of
both key ,finally release "DN" key earlier
than "UP" key
*ON-OFF must be done by logic input and
actual current greater than 0.2A must be
loaded.
OFF
rota /oFF / on
to indicate additional
factor besides basic
factor to indicate
running operation
value in a order
*OFF:to indicate basic factor orderly in
every 3 sec:V,I,KW(V*I*t*cos phi),GR
*ON:to indicate additional factor such as
Temp,PF,KWH,AWT(Accumulated
Working Time) including basic factor
together
* Possible to fix one of circulated factor or
to release:one touch button(CLR Key:enter
function)
OFF
hP-c /clear
to start to
accumulate KWH or
to clear accumulated
KWH
*to accumulate KWH from timed position
in every 6 min
*max accumulated KWH is 99999999
*To clear:press "UP" firstly-->keeping
pressed "UP" -->nextly,press "DN"
key ,then keep 1 sec under pressed state of
both key ,finally release "DN" key earlier
than "UP" key
0
rESEt/Hr/
AuL-#
to decide how to
reset trip state
*Hr:password input
*Er
:"Reset" button of converter
:"CLR" Key
:Control power : OFF
:Logic #2 input :OFF(High
⟶
Low)
*AuL-#(n times):Auto reset by followed
condition
:n=1:possible to do only by entering
password
:n>1
▸
1(once)
∼
(n-1) times: reset
automatically
according to preset reset time without
entering password
▸
n(last times)
:possible to do only by entering password
:trip state is kept on untill making
password
reset even though the control power is
off(password lock)
*Password reset:reset is done by comming
out from operating mode after input
password
Hr
Aut-t/
setting value
to preset auto reset
time
*time range :0(instant), 0.1sec,1~300sec
*If Hr is preset in "rESEt" mode, this
mode becomes disable
"--"
t-Aut/
setting value
to preset total
possible time
available for
executing defined
*possible total allowable time to have
the preset number of auto reset
*time range:30min~60min
*only possible for over current trip
"--"
