Au-o/ oFF/Ec/
uc/Shoc/AL/
tEMP/Ec-tE/
SS-tr/Ec-ta
/Ec-tb
to preset a kind of
AUX trip output
*oFF:to make same output as main trip
*Ec:only for ground fault protection
*Ec-ta:the state of 07-08 before trip is
"b"(close) , then takes trip action caused by
GR like same manner of the main trip
*Ec-tb:the state of 07-08 before trip is not
changed as "a"(open) , then takes trip
action caused by GR like same manner of
the main trip
*uc:only for under load/under current
*Shock:only for Shock/Stall
*AL:only for higher level alarm to oc
*tEMP:only for over temperature
*Ec-tE: only for one of Ec or temperature
*SS-tr:only for short circuit trip/ this trip
makes uniquely a main trip in the same
time
*This selected protection factor is excluded
in main trip naturally
*This trip is automatically reset if a trip
condition is clear
oFF
ALhc/oFF/
setting value
to preset higher
alarm level rate(%)
to OC(OL)
*oFF:if other factor except AL in this "Au-
o" mode is preset,this mod is displayed an
image like "ALhc-"
*% range:65% ~100% of preset value to
Load(KW)/OC
95
ALLc/oFF/
setting value
to preset lower alarm
level rate(%) to OC
*This mode is disable state like"__" in
case voltage value is preset in "LInE" mode
*The preset in this mode is possible only in
case "LInE" mode is in "OFF"
*to preset lower level % to
preset ”OC”("OL") value and range is
30%~under Alhc %
*This is able in case of lower level than
preset
value
“—“
ALt/setting
value
to preset a limit of
accumulated
working time
necessary to give
alarm.
*if 0.2A is loaded, working time is
accumulated in every 6 min
*setting range:0.1 hr ~6553.5 hr in 0.1 hr
step
*"Sec" LED of front window will be
flickered to give alarm after passing a
preset value for hour
*To clear:press "UP" or “DN” after
entering “ALT” mode in motor stop state,
but “—“ will be flickerd until 6 min has
passed after starting a motor
6500
dc
to decide max
current to change
into 20mA
*to transfer maximum current of 3 phase
current into 20mA ,and 4mA means zero
ampere output
*Primary current is transferred in case
external CT is used.
*The receiver for 4-20 signal does not
need loop voltage
5
tEMP/oFF/
Setting Value
to preset
temperature value to
protect temperature
rising
*based on PT100 sensor
*range: 1
O
C ~150
O
C/I
O
C a step
*if sensed temperature is greater than
preset value,restarting is not able
OFF
