Samwha DSP DSP-VIP-PL - 13-2. Sub Mode Settings

Test
*This is done by test sw on the converter or by pressing "CLR" key for 3 sec or more
*to check if this relay is ready to work normally or not.
*main trip output will be trip after counting down preset o-time (definite T-I;o-time,
inverse T-I:550% time of its class)
*need to make a reset to enter into operational condition as pressing “Reset SW in
Converter or “CLR” key for 0.5sec more,then “End” is shown
13-2. Sub Mode
Mode
Function/range
Description
Factory setting
value
P0000
Password
*same as a job of password mode in "main
Mode"
0000
Out /a / b
to decide initial state
of main trip relay
*to make initial state(a or b) of main trip
output(97-98) when control power is
powered
*a:normal energized type(open

close)
*b: normal deenergized type(not changed)
a
Fr-ty/a/b
to decide transferred
pattern for SC/F-
MC/R
*a:C1-MC/R is closed after C1-SC/F is
opened after preset time of Frdt mode is
elapsed
*b: C1-MC/R is closed after C1-SC/F is
kept close as preset time of Frdt mode is
elapsed
b
Frdt/oFF/setti
ng value
to preset transferred
time for SC/F-MC/R
*Adjustable time : 1sec~5 min
*SC-end~MC-start transit time : 0.2sec
*dt is available for each contactor while the
transaction is done
*OFF : transaction for F-R is not done,also
possible to have reverse operation in case
Logic
input #3 is used
b
uL/oFF/
setting value/
/[ uc/oFF]
to preset a range to
protect under
current/load
*this mode shows "uL" or "uC" according
to a selection(Load/KW) in DIP SW
*under load setting range with voltage
-110V:70W~Under OL preset value
-220V:135W~Under OL preset value
-380V:235W~Under OL preset value
-440V:270W~Under OL preset value
-480V:300W
∼
Under OL preset value
*under current setting range:0.1A~ under
preset value for "Oc"
OFF
ut/oFF/setting
value
to preset trip delay
time to protect under
load/current
*to preset trip delay time to protect under
load/current
*def:0.1~30sec
*in case ”uL” mode is OFF ,this mode is
displayed an image like "uL--", it means
this mode is disable
"--"
ub / oFF /
value
to preset current
unbalance rate(%)
among 3 phase
* even if Load is selected,this function is
available by actual current
*formular:[(max-min)/max]*100 [%]
*range:30% ~ 90%
*minimum available current:0.3A
50%
