Samwha DSP DSP-VIP-PL - Trip Relay Output; Main Trip Relay Outputs; Auxiliary Trip Relay Outputs

OV/UV
1a,Normal
de-energized
*In case "voltage" is selected
in Line Mode
.Over Voltage Trip
.Under Voltage Trip
.Voltage Unbalance
*In case "OFF" is selected in
Line Mode
-Lower alarm level(ALLc)
to OC,30%~ under Alhc
level
-Contact is closed after 3
sec under preset alarm
level,but main trip relay is
not trip.
-Only trip cause is appeared
in display window in the
position of voltage factor on
the way of continued
display rotation ,in case
this trip output is energized
during a motor runs.
*In case both OP & UP
mode is OFF in the same
time, then "SS" trip output
comes out through this
output
13.Preset Description
13-1.Main Mode
Mode Function/range Description
Factory Setting
value
P0000
Password
*Press "SET" button to have a preset.
*Input a factory setting number,"0000" to enter
setting mode
*Move a cursor from first digit(1000 unit) to last
digit(1 unit) to pass over next mode as pushing
CLR key(Enter function) 4 times.
*possible to change password made by "PEdIt"
mode in CAB mode group
*If the operator forget a password,
manufacturer can support it or use a procedure to
call factory initialized setting value
*To call factory seting value,make pressed state
for Test button of converter at first under power-
off condition, then power-on under pressed state of
test button for 3 sec or more
0000
