17.Current Range Table for external CT
Range
Number of
CT turn in
itself
Preset in "ct" mode
Preset in
"cto"
mode
Remarks
(ct ratio)
0.2A~70A
1 *Without external CT
1t
70 Type,Wide Range
1 *With external CT:0.2~6A
5t
0.4A~10A 1 2(10:5)
5A
*With external CT,
Secondary rating of CT is
5A
*CT ratio to preset is
1~600
0.6A~15A 1 3(15:5)
0.8A~20A 1 4 (20:5)
1.2A~30A 1 6 (30:5)
1.6A~40A 1 8 (40:5)
2A~50A 1 10(50:5)
2.4A~60A 1 12 (60:5)
3A~75A 1 15 (75:5)
4A~100A 1 20(100:5)
4.8A~120A 1 24(120:5)
3.6A~150A 1 30(150:5)
8A~200A 1 40(200:5)
10A~250A 1 50(250:5)
12A~300A 1 600(300:5)
16A~400A 1 80(400:5)
20A~500A 1 100(500:5)
24A~600A 1 120(600:5)
30A~750A 1 150 (750:5)
32A~800A 1 160(800:5)
40A~1000A 1 200(1000:5)
48A~1200A 1 240(1200:5)
60A~1500A 1 300(1500:5)
80A~2000A 1 400(2000:5)
100A~2500A 1 500(2500:5)
120A~3000A 1 600(3000:5)
