Samwha DSP DSP-VIP-PL - Accessory List

external CT
DSP-VIP-PM70B-CR
0.2∼70A,Converter+Display Meter+ MWR-S
+Terminal/24VAC/DC,
with external ZCT , 0.2~6
A with
external CT
DSP-VIP-PM70Z7-TCR
0.2∼70A,Converter+ Display Meter + MWR-S +
Terminal/85VAC∼
260VAC,50/60Hz,( 90VDC~370VDC),
with external ZCT , 0.2~6A with external CT
DSP-VIP-PM70Z7-ZCT-
PC
R
0.2∼70A,Converter+Display Meter+ MWR-S /Optional
Function program/85VAC∼
260VAC, 50/60Hz,
(
90VDC~370VDC),ZCT embedded
DSP-VIP-PM70B-ZCT-CR
0.2∼70A,Converter+Display Meter+ MWR-S
+Terminal/24VAC/DC,ZCT
Embedded
DSP-VIP-PM70Z7-ZCT-
TC
R
0.2∼70A,Converter+ Display Meter + MWR-S +
Terminal/85VAC∼
260VAC,50/60Hz,(90VDC~370VDC),Z
CT
Embeded
*Accessory
Item Refeence Description Remarks
Cable
DSP-CABLE-12
1.2m
DSP-CABLE-18
1.8m
DSP -CABLE-30
3m
DSP -CABLE-XX
Over 3m
ZCT
DSP -ZCT--XX
00mA/1.5mA
XX:Inner
diameter of
ZCT
DSP -ZCT-V-XX 100mA/100mV
Loader
DSP -ID-PL
Input Device/ Loader
Display Meter DSP -ID-PM
Input device/ Display
Meter
CT Terminal DSP -TB-3T
Terminal through CT
Hole
Communication
Module
DSP -CM-44
*Module RS 485/422<
>RS 485/422
RS485/422
Serial Comm.
Communication &
recorder Module
DSP-MWR-S
*Module:RS 485< >
RS 485
*Recorder for 20 days
in every second
RS485 Serial
communication
Protocol converter DSP-CMB
*Multi-1U/USB Combo @
Cross cable
*485(CM-44)< >232
USB(Note PC)
External CT
DSP-C1
3CT/Rectangular, 100/5
DSP-CC
3CT/Rectangular, 150/5
DSP-C2
3CT/Rectangular, 200/5
DSP-C3
3CT/Rectangular, 300/5
DSP-C4
3CT/Rectangular, 400/5
※Note
Logic input voltage is 220VAC(150~260 VAC)/220~370VDC unless “B” is suffixed in
completed reference code.
