This is only displayed on the IntelliLink software Operation screen; there is no
CLOSED-LOOP BREAK SWITCH LED on the faceplate. The faceplate displays the active
Shots to Lockout mode by blinking the SWITCH CLOSED LED, and on the LCD screen
under the “Maintenance” section as “Shots-to-Lockout: ON.
Hot Line Tag (Only applicable to SG6801 and SG6801E33 software)
The Hot Line Tag mode can be applied by selecting the On state. The Hot Line Tag
mode can be set by this button, by an IntelliLink software screen command, by a remote
IntelliLink software command, and by a SCADA command. The Hot Line Tag mode can
only be cleared by the same method used to set it.
Shots to Lockout Switch 1/2
This enables the Shots to Lockout mode, which is the congured number of three-phase
voltage losses that must be detected during the congured Shots to Lockout Time
Threshold setting before the control can trip open the switch.
Manual Operation
The Clear button clears a manual operation to return the IntelliTeam system to the
Ready state.
Clear Faults
The Clear button clears all fault indicators.
Clear Electronics Bad
The Execute button clears all bad electronics indicators.
Battery Status
This shows the overall status of the battery system:
Normal—Enough charge is present to operate the line switch.
Low—The battery is in a marginal condition, and line switch operation may or may not
be possible.
Bad—The battery charge is too low to operate the line switch.
Low ImpedanceBattery resistance is below 15 milliohms for 24- or 36-Vdc systems.
Battery Voltage
This shows the battery voltage under normal operating load with the charger disconnected.
If ac power is present, the switch control updates this voltage only during a battery test.
If ac power is not present, this is the real-time measurement of battery voltage.
Control Status
This can indicate:
OKAY—The control is functioning normally.
Alarm—The control is functioning normally but maintenance is required (for example,
battery replacement).
WarningThe control can function in a limited capacity (for example, loss of SCADA
communication).
ErrorThe control cannot function properly and may not be able to open or close.
Maintenance ModeThe control cannot function properly, and an application program
needs to be loaded.
IntelliLink
®
Setup Software
14 S&C Instruction Sheet 1045-530
