5
LCD Display
1 2 3 4 5 6 7
8
9
10
11
12
Product Overview
Main Unit
Name
Description
1. MENU • To access the menu mode
2.
button
• To move right in the menu / thumbnail mode / option
settings
• To display the next photo
3.
button • To move up in the menu / thumbnail mode / option
settings
4. Play / Pause
• To start / pause the slideshow
• To confirm a setting or function
5.
button
• To move left in the menu / thumbnail mode / option
settings
• To display the previous photo
6.
button • To move down in the menu / thumbnail mode /
option settings
7. Esc /
button • To return to the main menu
8. SD/MMC/MS slot • To accommodate SD, MMC, MS cards
9. USB host • To accommodate USB devices such as portable USB
flash drives or flash memory card readers
10. DC-IN socket • To connect to the mains
11. ON / OFF switch • To turn the unit on and off
12. Stand receptacle • To attach the supplied stand
