10
GB
INSTALLATION
- You may use the U-shaped drain hose holder to secure your drain hose and to avoid bending it.
- Secure the water drain hose to the waste pipe to avoid it coming off during the washing process.
• The waste pipe must only be connected to the foul drains and not the surface water drainage
system!
• The water drain hose should be placed between 40 cm and 100 cm from the floor level and
must not be extended, otherwise the unit may not be able to expel the waste water properly.
ST4 screws
U-shaped drain
hose holder
Water drain hose
SDW60W_X10N_IB_5L_100921.indb 10 21/09/2010 5:50 PM
