Location
When selecting a position for your unit make sure the oor is at and rm, and that the
room is well ventilated with an average room temperature of between 10°C and 32°C. Avoid
locating your unit near a heat source, e.g. a cooker, boiler or radiator. Avoid direct sunlight.
If you are placing your unit in an outbuilding such as a garage or annex ensure that the unit
is placed above the damp course, otherwise condensation will occur on the cabinet. Never
place the unit in a wall recess or into tted cabinets or furniture.
Levelling the Unit
To do this adjust the two levelling feet at the front of the unit. If
the unit is not level, the doors and magnetic seal alignments will
not be covered properly.
Installation
Free Space Requirements
When installing the unit, ensure that 25 mm
of free space is left at both sides, 50 mm at
the rear of the unit and 25 mm at the top of
the unit. The door can be opened to the right
or the left, depending on which best suits the
location. Please ensure there is more than
twice the width and depth distance space of
the unit to fully open the door to a maximum
angle of 160°.
Installing the Unit
Your wine cooler can be used as a freestanding or a built-in unit.
To use as a built-in unit, follow the dimensions below.
Max. 160°
Y mm
X mm
600
570
595
820~860
150
min.570
min.830
13
SIWC46B15E_IB_5L_150316_grace.indb 13 16/3/15 10:21 am
