Installing the Door Handle
• Ensure the unit is unplugged and empty.
• Adjust the two levelling feet to their highest position.
• To take the door o it is necessary to tilt the unit backwards. You should rest the unit on something
solid, e.g. a chair just below the top panel.
• All parts removed must be saved to do the reinstallation of the door.
• Do not lay the unit at as this may damage the coolant system.
• We recommend that 2 people handle the unit during assembly.
Reversing the Door Swing
Tools required: Philips style screwdriver / Flat bladed screwdriver / Hexagonal spanner.
1. Open the door and remove the two screws
under the right bottom corner of the door.
Remove the lower right hinge. Be careful to
support the door with both hands to prevent
it from dropping after removing the screws.
14
SIWC46B15E_IB_5L_150316_grace.indb 14 16/3/15 10:21 am
