12 Sanli Brushcutter User Guide
Using your accessories - straight shaft.
The shoulder strap see (Figure 22)
can be adjusted in length for the
convenience of the operator and
hooks onto the eyelet on the shaft.
Please note the hip guard should be
placed between the body and the
brushcutter.
Attaching the
cutting blade
(straight shaft model only).
When heavy duty cutting is required
utilise the cutting blade (Figure 23).
Remove the trimmer bump head
(refer to fi gure 5) and rotate opposite
direction. Then place the cutting blade
as shown and tighten in anti-clockwise
direction.
Order of components to attach the
cutter blade (Figure 24).
Figure 22.
Figure 23.
Figure 24.
