SANLI BCB260 - Attaching Trimmer Head; Straight Shaft Model; Bent Shaft Model

Sanli Brushcutter User Guide 7
Attaching the trimmer
head - straight shaft.
Insert the allen key provided into the
hole on the gear head to stop it from
rotating. Remove the nut, tension
washer and brass ring as shipped and
put in a safe place. These parts are
required when fi tting the cutting blade
which is supplied with this unit.
Insert the allen key provided into the
hole on the gear head to stop it from
rotating. Then wind the trimmer head
anti-clockwise onto the head see
(Figure 6).
Insert the allen key provided into the
hole on the gear head to stop it from
rotating. Then wind the trimmer head
clockwise onto the head (Figure 7).
Figure 5.
Figure 7.
Figure 6.
Attaching the trimmer
head - bent shaft.
