10
Santa Fe Compact2 Installation & Operation Instructions www.Santa-Fe-Products.com | 1-800-533-7533
Air Filtration
The Santa Fe Compact2 is equipped with a pre-filter and a MERV-8 air filter. An optional MERV-11 filter is available at
www.Santa-Fe-Filters.com.The filters should be checked and replaced every three to six months. Operating the unit with
a dirty filter will reduce dehumidifier capacity and efficiency.
DO NOT operate the unit without the standard MERV-8, or optional MERV-11 filter. Filter non-compliance voids the
product warranty.
Changing the Filter
For greatest filtration and efficiency of the Santa Fe Compact2, it is recommended the air filters be replaced
every three to six months.
Step 1 - Removing the Filters:
Remove the 1/4” pre-filter by gently pulling on the bottom of the filter frame.
Remove the MERV-8 filter by gently pulling on the bottom of the filter frame.
Step 2 - Installing the Filters:
Angle the top of the MERV-8 filter and gently slide the filter into the filter slot. Do not force. If resistance is felt,
check alignment for obstructions or debris inside the filter housing. Be sure the arrows on the filter are facing
into the dehumidifier.
Angle the top of the pre-filter and gently slide the filter into the filter slot (in front of the MERV-8 filter). Do not
force. If resistance is felt, check alignment for obstructions or debris inside the filter housing.
CAUTION!
MAKE SURE UNIT IS OFF BEFORE CHANGING THE FILTER. FAILURE TO FOLLOW FILTER HANDLING
INSTRUCTIONS MAY RESULT IN IMPROPER FUNCTION OF THE DEHUMIDIFIER AND CAUSE
PREMATURE FILTER WEAR OR UNIT DAMAGE.
Pre-Filter
MERV-8 Filter MERV-8 Filter
MERV-8 Filter
Pre-Filter
MERV-8 Filter
To Next Page
