Santos 4 - Parts Identification Table

SANTOS : User and maintenance manual
98101 US 3.3 - 07 2013 19 / 20 www.santos.fr
ITEM
Description
1
Bean hopper cover
2
Bean hopper
3
Bean hopper shutter
4
Adjusting dial
5
Adjuster button attachment
6
Grinding wheel gap adjuster button
7
Dial fastening screw
8
Bag grip cord
9
Bag grip strap
10
Grind outlet tube
11
Base
12
Non-slip feet
13
On-off switch
14
Thermal overload switch, with reset
15
Grinding unit
16
Grinding unit clamp nut
17
Grinding wheels
18
Mobile grind wheel carrier plate
19
Fixed grind wheel carrier plate
