Santos 55 - 110-120 V 50;60 Hz and 220-240 V 50;60 Hz Wiring Diagram

SANTOS: User and maintenance manual
98155 EN 3.7- 05 2014 18 / 22 www.santos.fr
110-120V 50/60Hz and 220-240V 50/60Hz wiring diagram
Black
~
Red
Motor
Blue
White
White
White
Black
Capacitor
Green / yellow
Black
White
Black
Filter holder
presence
micro-switch
Control panel
Control part
Harness
E
lectronic card
Power part
2
4
5
1
On / Off
PP
PA
Filter carrier presence
micro
-switch
White
Red
Blue
Orange
Orange
Purple
Purple
Brown
1
2
3
4
5
6
7
8
9
10
