Adjustments
To level your TV, turn the level adjustment screw
S
on
the top of either TV bracket
01
or
02
to raise or lower
that respective side of the TV.
Your TV should adjust easily when moved, then stay in place.
Adjust the tilt tension knob
T
if your TV naturally tilts up or down.
NOTE: If you do not intend to adjust the tilt for different viewing
locations, you can tighten the tilt tension knobs
T
to prevent
unwanted movement.
Raise
0102
Lower
S
Tighten
Loosen
T
LEVEL Tilt
