31
Troubleshooting
TV Supplied
Spacer
TV supplied spacers
CAUTION: Avoid potential injury or property damage!
Use the correct screw length for adequate thread engagment.
CAUTION: Avoid potential injury or property damage!
Use the correct screw length for adequate thread engagment.
TV Supplied
Spacers
a
FLAT BACK
a: Use your TV supplied spacer for flat back TVs (AND you want
your TV closer to the wall).
b: Use your TV supplied spacer and spacer
05
for:
● Round (irregular) back TVs ● Extra space needed for cables
– Too short will
not hold the TV.
– Too long will
damage the TV.
– Too short will
not hold the TV.
– Too long will
damage the TV.
Too Short
Too Short
Too Long
Too Long
Correct
Correct
If you are uncertain about your hardware selection,
contact Customer Service at 1-800-359-5520.
TV Supplied
Spacer
b
ROUND BACK CABLES
05
