STEP 1
Attach Brackets to TV
NOTE: Not all hardware included will be used.
WARNING: This product contains small items that could be a choking hazard if swallowed.
Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged
item to your dealer; contact Customer Service. Never use damaged parts!
Parts and Hardware for STEP 1
M8 x 50mm
For concrete installations ONLY
2.5mm
22mm
M6 x 12mm
M6 x 20mm
M6 x 35mm
M8 x 40mm
M8 x 20mm
M8x30 mm
5mm
5/16 x 2¾ in.
5/16 in.
Right TV
Bracket
Left TV
Bracket
TV Screws
TV Washers
Spacers
03 x4
04 x4
05 x4
01 x1
02 x1
To Next Page
