17
Arm Tension
Screw
14 mm (9/16 in.)
socket
REMOVING THE TV
To remove your TV from the
wall plate assembly
13
,
disconnect all cables and then
reverse the
procedures in STEP 3.
SWIVEL ADJUSTMENT
Your TV should adjust easily when moved,
then stay in place.
If your TV is too loose or too tight, adjust
the arm tension screws using hex key
18
and a 14 mm (9/16 in.) socket.
EXTENSION/RETRACTION ADJUSTMENT
Your TV should adjust easily when moved,
then stay in place.
If your TV is too loose or too tight, adjust
the arm tension screws using hex key
18
.
13
18
Arm Tension
Screw
18
Loosen
Loosen
Tighten
Tighten
HEAVY! You may need
assistance with this step.
