Sanus FSF110 - Page 3

3
Before getting started, let’s make sure this mount is perfect for you!
2.95
[75.0]
3.94
[100.0]
2.95
75.0
3.94
100.0
7.87
200.0
7.87
200.0
10.42
264.8
6.40
162.5
16°
16°
0.86
21.9
OFFSET
3.16
80.3
8.50
215.9
3.03
77.0
3° ROLL LEFT
3° ROLL RIGHT
TV INTERFACE
WALL PLATE
FULLY ASSEMBLED MOUNT
TOP VIEW - EXTENDED
TOP VIEW - RETRACTED
SIDE VIEW - EXTENDED
SIDE VIEW - RETRACTED
3-D
in.
[mm]
Dimensions
