Sanus FSF110 - Page 5

5
THIS WAY UP
5/16 x 2 ½ in.
8-32 in.
8-32 x 3⁄8 in.
7/32 in.
5/16 x 2¾ in.
Fischer UX10 x 60R Anchor
STEP 2 Parts and Hardware
STEP 3 Hardware
Additional Hardware
Wall Plate
Assembly
Wall Plate Template
12
Lag Bolts
14
x2
x1
13
x1
x1
15
x1
16
Washer
Hex Key
Cable Ties
x1
18
x3
17
Locking Screw
STEP 2B: CONCRETE INSTALLATIONS
Concrete Installation Kit CMK1
[NOT INCLUDED]
Lag Bolt
Concrete Anchor
C2
x2
C1
x2
Contact Customer Service to inquire
about the addition hardware.
