Supplied Parts and Hardware
WARNING: This product contains small items that could be a choking hazard if swallowed.
Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged
item to your dealer; contact Customer Service. Never use damaged parts! NOTE: M4, M5, M6, or M8 describes the diameter, mm describes
the length of screws that are labeled M# X ##mm. Not all hardware included will be used.
Speci cations
Weight capacity-includes TV and any accessories-DO NOT EXCEED:
Ù ML11 45 kg (100 lb.)
Ù LL11 68 kg (150 lb.)
CAUTION: Avoid potential personal injuries and property damage!
Ù Do not use this product for any purpose not explicitly speci ed by manufacturer.
Ù The wall must be capable of supporting ve times the weight of the monitor and mount combined.
Ù This product includes directions and hardware for use with wood stud, solid concrete and concrete block walls.
Ù If you do not understand these instructions, or have doubts about the safety of the installation, assembly or use of this product, contact
manufacturer Customer Service or call a quali ed contractor.
Ù Manufacturer is not responsible for damage or injury caused by incorrect assembly or use.
10mm
(3/8 in.)
5mm
(3/16 in.)
Required Tools
English
[01] x 1
[02] x 2
[01] x 1
[02] x 2
LL11 ML11
To Next Page
