Sanus LT25 - Page 11

11
3
4
3. Drill the four pilot holes using a 3/16 in. (5 mm) diameter drill bit.
IMPORTANT: Pilot holes must be drilled to a depth of 2 ½ in. (63 mm).
4. Install the four washers
25
and lag bolts
26
. Tighten all four lag bolts
26
only until the washers
25
are pulled firmly against the wall plate
23
.
CAUTION: Avoid potential personal injury or property damage! All four lag bolts
26
MUST BE firmly tightened to prevent unwanted
movement of the wall plate
23
.
Ensure the wall plate is securely fastened to the wall before continuing on to the next step.
Go to PAGE 14.
25
26
23
3/16 in.
(5 mm)
2½ in.
(63 mm)
