6901-002090 <00>
12
M6 M6
M8
For TVs with a at back. Ensure that the bracket is level on the back of
the TV. Standard con gurations are shown. If you need extra space to
accommodate cables, recesses, or protrusions, see the installation option
(1-2) that uses spacers. For special applications, or if you are uncertain about
your hardware selection, contact Customer Service.
?
1-1
[10]
[11]
[13]
[16]
[16]
[16]
[01]
[01]
[01]
[01]
