Sanus MLF13 - Step 3: Attach Arm Assembly to Wall Plate; Attach TV to Arm Assembly

12
STEP 3 Attach Arm Assembly to Wall Plate/Attach TV to Arm Assembly
1 2
17
17
20
20
21
24
1. Hang the arm assembly
20
onto the wall plate
17
.
2. Install the wall plate screws
21
using the 3/16 in. hex key
24
.
CAUTION: Avoid potential injuries or property damage! Ensure the wall plate screws
21
are secure. Periodic tightening may be required.
