Sanus MLL11 - Drill Pilot Holes; Secure Wall Plate with Lag Bolts

9
3
4
3. Pilot holes MUST be drilled to a depth of 3 in. (75 mm), using a 7/32 in. (5.5 mm) diameter drill bit.
3. Tighten the lag bolts
17
only until the washers
16
are pulled firmly against the wall plate
14
.
CAUTION: Avoid potential injuries or property damage! Improper use could reduce the holding power of the lag bolt
17
.
To avoid potential injuries or property damage. DO NOT over-tighten the lag bolts
17
.
3 in.
(75 mm)
7/32 in.
(5.5 mm)
14
17
16
