8
STEP 1 Option A Attach to a Wall Mount WITH Slots
Before installing panel
01
, install the TV brackets
B
onto the TV. If the TV is already mounted to the wall, you may need to remove
it for better access. Refer to your TV mount’s installation manual for TV bracket assembly or TV removal.
Attach panel
01
on either TV bracket
B
fi t the tabs of the panel into the side slots of the TV bracket
B
. Secure the panel with the
M4 x 6 mm retaining screw
03
.
Continue with STEP 2 on PAGE 14.
01
B
01
B
NOTE: DO NOT install more than 2 panels.
Interference?
Move TV
brackets
B
up or down
on the TV
to clear the
notch.
03
01
