Sanus SLF5 - Secure TV Bracket Assembly

10
Center the horizontal TV brackets
02
and vertical TV support
01
over the hole pattern on your TV.
NOTE: If the vertical TV support
01
is not centered, you may need to reposition the horizontal TV supports
02
(see previous step 1-3).
Secure the assembly with the four interface nuts
14
using hex key
25
.
1-4 Secure TV Bracket Assembly
14
25
01
02
02
