Sanus SLF5 - Attach TV to Arm Assembly

17
1
HEAVY! You may need assistance with this step.
3-2 Attach TV to Arm Assembly
2
1. Hang the TV onto the arm assembly
20
by first hooking the top support, then resting the TV into place.
2. Lock the TV to the arm assembly
20
with safety screw
22
using hex key
25
.
CAUTION: Avoid potential personal injury or property damage! This safety screw
22
must be installed to secure the TV onto the arm
assembly
20
.
20
20
Top Support
22
25
