Sanus SLF9 - Attach TV to Arm Assembly

19
HEAVY! You may need assistance with this step.
3.2 Attach TV to Arm Assembly
2
24
27
30
1
1. Hang the TV onto the arm assembly
24
by first hooking the hang tab
H
, then resting the TV into place.
2. Lock the TV to the arm assembly
24
with locking screw
27
using hex key
30
.
CAUTION: Avoid potential personal injury or property damage! Locking screw
27
must be installed to secure the TV to the arm assembly
24
.
H
24
