CAUTION: Avoid potential personal injuries and property damage!
● Drywall covering the wall must not exceed 5/8 in. (16 mm)
● Minimum wood stud size: common 2 x 4 in. (51 x 102 mm) nominal 1 ½ x 3 ½ in. (38 x 89 mm)
● Minimum horizontal space between fasteners: 16 in. (406 mm)
● Stud centers must be verified – not all walls have conventional 16 in. (406 mm) stud spacing
1. Locate studs. Verify the center of the stud(s) using an awl, a thin nail, or an edge to edge stud finder.
2. Level the wall plate template
19
and mark the hole locations in the center of the studs.
HERE WE GO!
Scan here to vi
ew
your i
nstall
video.
Model: SLF8-B1
6700-004620 <00>
Locate your studs and choose a height for your
TV, then
simply tape this template to the wall,
and you
can drill right through.
san.us/969
san.us/971
THIS IS YOUR DRILLING TEMPLATE
FOR STEP 2
WELCOME AND THANKS FOR CHOOSING SANUS SIMPLICITY
YOU’RE REALLY GOING
TO ENJOY STEP 3
Once the wall plate is installed,
attach the arm to the
wall plate. Next, simply pick-up your TV, hang it on the
a
rm, and
secu
re it. Congratulations! You’r
e done.
We'r
e here to help!
If you have quest
i
ons at any point, contact customer service at
:
1-888-333-1376
Monda
y
– F
riday 8
AM
–
9
P
M
C
ST
Saturday – Sunday 10:30
A
M
– 7
PM
CST
F
r
om your typical viewing location, position your TV so
your eyes a
re level with the middle of the sc
reen. Fo
r mo
st
p
eople, th
is is betw
een 40
"
and 60 " (101 cm and 152 cm)
above the fl
oor
. For p
recise drilling locations, scan the
HeightWizard
™
link below or contact customer service.
GET STARTED
WITH STEP 1
VIEWING HEIGHT
RECOMMENDATION
Grab the TV brackets and line them up
with the holes on the back of your TV.
Attach using the bolts that fit.
Reference the
product man
ual for
details on mountin
g to conc
rete.
Be su
r
e to
review t
he manual for
comple
te saf
ety instruct
i
ons.
40 –
60 in.
101 – 152 cm
10
°
10
°
THIS WAY UP
1
2
NOTE: For assistance in
determining wall plate location, try our
HeightFinder
™
at Simplicity.Sanus.com
Min. 16 in.
(406 mm)
Max.
5/8 in.
(16 mm)
STEP 2A Wood Stud Installation
UP ARROW
19
To Next Page
