Sanus SLT3 - Step 2 B: Attaching Wall Plate (Concrete Installation) - Continued; Inserting Concrete Anchors; Securing Wall Plate in Concrete

13
3 4
3. Remove the wall plate template
18
and insert concrete anchors
22
.
CAUTION: Be sure the anchors are seated flush with the concrete surface.
4. Install the wall plate
19
using four lag bolts
20
and washers
21
. Tighten all lag bolts only until they are pulled firmly against the wall plate.
CAUTION: Improper use could reduce the holding power of the lag bolt. DO NOT over-tighten the lag bolts.
Go to STEP 3 on PAGE 19.
21
20
22
19
