1.5 Remove Extensions [200 x 100 mm, 100 x 100 mm, and 75 mm x 75 mm]
If mounting to a TV with; 200 x 100 mm (7 ⅞ x 4 in.),
100 x 100 mm (4 x 4 in.), or 75 x 75 mm (3 x 3 in.) hole
patterns, remove the extension plates from the TV
bracket
01
using a screwdriver and wrench.
NOTE: Extension nuts are poly-locks and may
need a wrench to remove.
01
When fi nished,
200mm x 100mm
Go to PAGE 10
100mm x 100mm
Go to PAGE 11
75mm x 75mm
Go to PAGE 12
