7
1-3 Attach TV Bracket
Position the TV bracket
01
over your TV hole pattern and install using the screw, washer, and spacer (if needed) combination you selected for
your TV.
M6/M8 spacer, screw, and washer
01
02
10
04
11
05 07
0310
11
13
12 10
M4/M6/M8 screw and washer
M4 spacer, screw, and washers
08
06 09
To Next Page
