14
STEP 2A
(continued)
Go to STEP 3 on PAGE 18.
6
SECURELY TIGHTEN
All lag bolts
11
MUST BE firmly tightened to prevent unwanted movement of the wall plate
10
.
Ensure the wall plate is securely fastened to the wall before continuing on to the next step.
CAUTION: Avoid potential personal injury or property damage!
Extended Wall Plate
2 ¾ in. (6.9 cm)
7/32 in.
(5.5 mm)
5
DRILL
11
09
10
11
10
