Sanus VXT7-B2 - Page 23

23
Dimensions
in. [mm]
7.87
[200.0]
16.73
[425.0]
31.50
[800.0]
43.31
[1100.0]
8.00
[203.2]
11.81
[300.0]
16.00
[406.4]
17.72
[450.0]
23.62
[600.0]
24.00
]609.6[
8.86
[225.0]
12.00
[304.8]
12.00
ø 0.33
[8.4]
8.00
6.98
[203.2]
[177.4]
12.20 [310.0]
5.50 [139.7]
10.93 [277.7]
6.22
[157.9]
DETAIL
33.43
[849.1]
MIN WALL PLATE
32.49
[825.3]
52.93
[1344.5]
MAX WALL PLATE
17.53
[445.3]
ESTIMATED 55" TV WITH
CENTERED 400X400 VESA
10°
7°
2.42
[61.6]
TV INTERFACE
WALL PLATE
WALL PLATE OPENING
FRONT VIEW
SIDE VIEW - HEIGHT ADJUSTMENT
TILT RANGE
SIDE VIEW - DEPTH
3-D
1" POST INSTALLMENT
HEIGHT ADJUST
FOR SMALL PARTS PANEL
