Service Manual SM CE14A2-C
2
5. TECHNICAL CHARATERISTICS.
Cathode-ray tubes
In-Line, Hi-bipotential gun. 14” (34 cm)
Tuning-system
Voltage synthesis, 100 programs in non-volatile memory, AFT, Fine-tuning (10 first
programs), automatic, semiautomatic and manual channel-search.
Band I, channels 2-4 (VHF)=E2-E4
Cable channels S1-S20
Hyperband channels S21-S41
Band III, channels 5-12 (VHF)=E5-E12
Band IV-V, channels 21-69 (UHF)=E21-E69
Reception system
B/G Model CE14A2-C
B/G-D/K Model CE14A2-E
B/G-L-L’ Model CE14AS2-F
Colour system
PAL, NTSC 4.43, N.A.P. (NTSC Amusement by PAL)Models
CE14A2-C, CE14A2-E
PAL/SECAM ntsc 4,43, N.A.P. Model CE14AS2-F
Program selection
Sequential selection from the controls on the set. Direct selection to any program
from the remote-control device.
Audio
Power-rating 1W rms. (10% distortion)
Speakers
1 of 8
Ω
.
Aerial
External aerial sockets 75 Ω IEC
Jack for headphones
Mono jack 3,5mm.
Clock and alarm Function
Timer Function
Switch on and off of CTV programmable in real time.
AV connectors
1 Scart connector 21 pin CENELEC standard AV, RGB and S_Video.
1 RCA Video input (frontal)
1 RCA Audio input (frontal)
Power supply
220 – 240 VAC 50Hz
Consumption
47W (maximum consumption).
29W (IEC 107-1)
3,1 W (Stand-by
)
Radio
87.5 – 108MHz. 40 memories. Manual and semiautomatic search
Hotel mode
Hotel mode and Hotel Rental
Options by means of Technical Service:
NTSC-M
6. Safety
It fulfils the safety requirements established in the regulation:
• EN 60065:93
7. EMC (Electromagnetic Compatibility)
It fulfils the EMC requirements established in the regulation:
• EN 55013:1990/A12:1994
• EN 55020:1994
• EN 60555-2:1987
