Ref. No. Part No. Description Ref. No. Part No. Description
7
12. PARTS LIST
PCB SOCKET TRC
CON.FG 0160221107 Polarized Band Gray 4P. 260/6/6
CON.FI 0160260303 Polarized Band Gray 8P. 330/6/6
CON.FK 0640202610 Earth Wire 270 mm.
CAPACITORS
C501 0230280307 Ceramic SMD 220 pF. 5% 50V. 0805
C502 0230280307 Ceramic SMD 220 pF. 5% 50V. 0805
C503 0230280307 Ceramic SMD 220 pF. 5% 50V. 0805
C504 0270341324 Polyester 100 nF. 10% 250V.
C511 0230320301 Ceramic SMD 470 pF. 10% 50V. 0805
C512 0230320301 Ceramic SMD 470 pF. 10% 50V. 0805
C513 0230320301 Ceramic SMD 470 pF. 10% 50V. 0805
C561 0230600603 Ceramic SMD 100 nF. +80-20% 25V.
C571 0230320301 Ceramic SMD 470 pF. 10% 50V. 0805
C573 0240590901 Ceramic 2200pF +80-20% 2KV.
DIODES
D501 0360601512 SMD LS4148
D502 0360601512 SMD LS4148
D503 0360601512 SMD LS4148
D504 0360601512 SMD LS4148
D505 0360104202 Zener BZX79C6V2
D561 0360605414 Zener SMD BZT55C9V1
D562 0360605604 SMD BAV103 200V 0,25A
D570 0360601512 SMD LS4148
FG1 0330144205 Ribbon Wire Holder 4 P.
FI1 0330163304 Ribbon Wire Holder 8 P.
J500 0470040007 Jumper Lead 0,6 mm.
PCB04
0750152415 Socket PCB EC7-A
TRANSISTORS
Q501 0360161319 BF 422 TPE2
Q502 0360161319 BF 422 TPE2
Q503 0360161319 BF 422 TPE2
Q511 0360160709 BF 423
Q512 0360160709 BF 423
Q513 0360160709 BF 423
Q570 0360321301 SMD BC 857 B
RESISTORS
R501 0790578140 Metal Oxide 15 KΩ 5% 2W.
R502 0790578116 Metal Film 15 KΩ 5% 2W.
R503 0790578116 Metal Film 15 KΩ 5% 2W.
R504 0790036909 Carbon 1,5 KΩ 5% 1/2W.
R505 0790255004 R.M.G. SMD 22 KΩ T<=5% 0805
R511 0790227003 R.M.G. SMD 100 Ω T<=5% 0805
R512 0790227003 R.M.G. SMD 100 Ω T<=5% 0805
R513 0790227003 R.M.G. SMD 100 Ω T<=5% 0805
R521 0790735203 R.M.G. SMD 510 Ω T<=5% 0805
R522 0790735203 R.M.G. SMD 510 Ω T<=5% 0805
R523 0790735203 R.M.G. SMD 510 Ω T<=5% 0805
R531 0790223002 R.M.G. SMD 47 Ω T<=5% 0805
R532 0790223002 R.M.G. SMD 47 Ω T<=5% 0805
R533 0790223002 R.M.G. SMD 47 Ω T<=5% 0805
R541 0790036909 Carbon 1,5 KΩ 5% 1/2W.
R542 0790036909 Carbon 1,5 KΩ 5% 1/2W.
R543 0790036909 Carbon 1,5 KΩ 5% 1/2W.
R551 0790037709 Carbon 3,3 KΩ 5% 1/4W.
R552 0790037709 Carbon 3,3 KΩ 5% 1/4W.
R553 0790037709 Carbon 3,3 KΩ 5% 1/4W.
R561 0790251003 R.M.G. SMD 10 KΩ T<=5% 0805
R562 0790127104 Carbon 100 Ω 5% 1/4W.
R571 0790741805 R.M.G. SMD 1,5 KΩ T<=5% 0805
R572 0790234702 R.M.G. SMD 430 Ω T<=5% 0805
R573 0790529614 Metal Film 2,7 Ω 5% 2W.
R574 0790036909 Carbon 1,5 KΩ 5% 1/2W.
ZOCALO
0330163205 CRT Socket MINI NECK ONE Ground
MAIN PCB
CF200 A2-C 0090411109 Ceramic Filter 5,5 MH.
CF200 A2-E 0090412701 Ceramic Trap Filter 5,5/6,5 MHZ
CF200 AS2-F 0090412701 Ceramic Trap Filter 5,5/6,5 MHZ
CF201 A2-E 0090412800 Ceramic Filter 6,5 MHZ.
CF202 0090412503 Ceramic Filter 5.5 MHz.
CN.FB 0160202305 Polarized Band Gray 2P. 280/6/6
CAPACITORS
C108 0230170318 Ceramic SMD 27 pF. 5% 50V. 0805
C109 0230170318 Ceramic SMD 27 pF. 5% 50V. 0805
C110 0230600603 Ceramic SMD 100 nF. +80-20% 25V.
C111 0250320769 Electrolytic 10 µF. 16V.
C112 0230600603 Ceramic SMD 100 nF. +80-20% 25V.
C114 0230360406 Ceramic SMD 1000 pF. 10% 50V. 0805
C115 0250461266 Electrolytic 100 µF. 16V.
C116 0230240327 Ceramic SMD 100 pF. 5% 50V. 0805
C117 0230160327 Ceramic SMD 22 pF. 1% 50V. 0805
C118 0230440125 Ceramic SMD 4700 pF. 10% 50V. 0805
C123 0230440125 Ceramic SMD 4700 pF. 10% 50V. 0805
C124 0230600603 Ceramic SMD 100 nF. +80-20% 25V.
C125 0230160327 Ceramic SMD 22 pF. 1% 50V. 0805
C126 0230360406 Ceramic SMD 1000 pF. 10% 50V. 0805
C127 0230280307 Ceramic SMD 220 pF. 5% 50V. 0805
C128 0230480600 Ceramic SMD 10 nF. +80-20% 50V 0805
C129 0230480600 Ceramic SMD 10 nF. +80-20% 50V 0805
C200 0250320769 Electrolytic 10 µF. 16V.
C201 0230190308 Ceramic SMD 39 pF. 5% 50V. 0805
C202 0230360406 Ceramic SMD 1000 pF. 10% 50V. 0805
C203 A2-E 0230480600 Ceramic SMD 10 nF. +80-20% 50V 0805
C204 0230600504 Ceramic SMD 100 nF. 10% 25V. 0805
C205 0230740003 Ceramic SMD 2,2 µF. 10V. +80-20%
C206 0230740003 Ceramic SMD 2,2 µF. 10V. +80-20%
C208 AS2-F 0230740003 Ceramic SMD 2,2 µF. 10V. +80-20%
C209 0230220204 Ceramic SMD 68 pF. 5% 50V. 0805
C210 A2-E 0230220204 Ceramic SMD 68 pF. 5% 50V. 0805
C211 A2-E 0230480600 Ceramic SMD 10 nF. +80-20% 50V 0805
C212 A2-C 0790701106 R.M.G. SMD 0 Ω 1/10W. 0805
C212 A2-E 0230360406 Ceramic SMD 1000 pF. 10% 50V. 0805
C212 AS2-F 0790701106 R.M.G. SMD 0 Ω 1/10W. 0805
C250 0230600603 Ceramic SMD 100 nF. +80-20% 25V.
C251 0250461266 Electrolytic 100 µF. 16V.
C252 0270370588 Polyester 180 nF. 10% 63V.
C256 0230480600 Ceramic SMD 10 nF. +80-20% 50V 0805
C257 0270370588 Polyester 180 nF. 10% 63V.
C260 0250410867 Electrolytic 47 µF. 16V.
C302 0230720203 Ceramic SMD 1 µF. 16V. +80-20% 0805
C304
!
0230360406 Ceramic SMD 1000 pF. 10% 50V. 0805
C305 0250410867 Electrolytic 47 µF. 16V.
C306 0250360468 Electrolytic 22 µF. 16V.
C310 0230520405 Ceramic SMD 22 nF. 10% 50V. 0805
C323 0230480600 Ceramic SMD 10 nF. +80-20% 50V 0805
C324 0250500667 Electrolytic 220 µF. 16V.
C325 0250141462 Electrolytic 470 µF. 16V. 8X11,5
C326 0230600504 Ceramic SMD 100 nF. 10% 25V. 0805
C400 0250461266 Electrolytic 100 µF. 16V.
C401 0230600603 Ceramic SMD 100 nF. +80-20% 25V.
C402 0230680308 Ceramic SMD 470 nF. 10% 16V. 0805
C403 0230520405 Ceramic SMD 22 nF. 10% 50V. 0805
C404 AS2-F 0230640401 Ceramic SMD 220 nF. 10% 16V.0805
C405 0230360406 Ceramic SMD 1000 pF. 10% 50V. 0805
C406 0230600504 Ceramic SMD 100 nF. 10% 25V. 0805
C408 0230520405 Ceramic SMD 22 nF. 10% 50V. 0805
C409 0230520405 Ceramic SMD 22 nF. 10% 50V. 0805
C410 0230520405 Ceramic SMD 22 nF. 10% 50V. 0805
C411 0230150229 Ceramic SMD 18 pF. 1% 50V. 0805
C412 0230600504 Ceramic SMD 100 nF. 10% 25V. 0805
C413 0230420119 Ceramic SMD 3300 pF.10% 63V.0805
C414 0230520405 Ceramic SMD 22 nF. 10% 50V. 0805
C415 0250461266 Electrolytic 100 µF. 16V.
C416 0230600504 Ceramic SMD 100 nF. 10% 25V. 0805
C417 0230400103 Ceramic SMD 2200 pF. 10% 50V. 0805
C418 0230420119 Ceramic SMD 3300 pF.10% 63V.0805
C419 0230740003 Ceramic SMD 2,2 µF. 10V. +80-20%
C420 0230720203 Ceramic SMD 1 µF. 16V. +80-20% 0805
C421 0230440125 Ceramic SMD 4700 pF. 10% 50V. 0805
C422 0230180226 Ceramic SMD 33 pF. 1% 50V. 0805
