Sanyo CE14A2-C User Manual

Service Manual SM CE14A2-C
Ref. No. Part No. Description Ref. No. Part No. Description
8
C423 0240136010 Ceramic 1000 pF. 10% 100V.
C424 0230600504 Ceramic SMD 100 nF. 10% 25V. 0805
C425 0270342603 Policarbonate 100 nF. 5% 63V.
C426 0250320769 Electrolytic 10 µF. 16V.
C427 0230600504 Ceramic SMD 100 nF. 10% 25V. 0805
C428 0230480600 Ceramic SMD 10 nF. +80-20% 50V 0805
C429 0240136010 Ceramic 1000 pF. 10% 100V.
C430 0230740003 Ceramic SMD 2,2 µF. 10V. +80-20%
C431 0230440125 Ceramic SMD 4700 pF. 10% 50V. 0805
C433 0230240327 Ceramic SMD 100 pF. 5% 50V. 0805
C434 0250320769 Electrolytic 10 µF. 16V.
C435 0230600504 Ceramic SMD 100 nF. 10% 25V. 0805
C438
!
0230360406 Ceramic SMD 1000 pF. 10% 50V. 0805
C440
!
0230480600 Ceramic SMD 10 nF. +80-20% 50V 0805
C441
!
0230360406 Ceramic SMD 1000 pF. 10% 50V. 0805
C600 0270220726 Polyester 10 nF. 10% 250V.
C601 0270301039 Polyester 47 nF. 5% 63V.
C603 0270381080 Polyester 220 nF. 10% 63V.
C611 0230600603 Ceramic SMD 100 nF. +80-20% 25V.
C651 0260210604 Polypropylene 8200 pF 3,5% 1600V
C653 0270410004 Polyester 390 nF. 5% 250V.
C655 0270100522 Polyester 1000 pF. 10% 400V.
C656 0270290802 Polyester 39 nF. 5% 400V.
C657 0270210628 Polyester 8200 pF. 10% 250V.
C668 0250323201 Electrolytic 10µF 160V
C670
!
0230240327 Ceramic SMD 100 pF. 5% 50V. 0805
C674 0230520405 Ceramic SMD 22 nF. 10% 50V. 0805
C675 0230600504 Ceramic SMD 100 nF. 10% 25V. 0805
C676 0230680308 Ceramic SMD 470 nF. 10% 16V. 0805
C678 0230680308 Ceramic SMD 470 nF. 10% 16V. 0805
C700 0250461464 Electrolytic 100 µF. 35V.
C701 0250461464 Electrolytic 100 µF. 35V.
C702 0250461464 Electrolytic 100 µF. 35V.
C703 0270381080 Polyester 220 nF. 10% 63V.
C711
!
0230360406 Ceramic SMD 1000 pF. 10% 50V. 0805
C713
!
0230360406 Ceramic SMD 1000 pF. 10% 50V. 0805
C714
!
0230360406 Ceramic SMD 1000 pF. 10% 50V. 0805
C800
!
0270342702 Polyester 100 nF. 20% 275V.AC
C801 0240134767 Ceramic 1000 pF. +-20% 1KV.
C802 0240134767 Ceramic 1000 pF. +-20% 1KV.
C803 0250464369 Electrolytic. 100 µF. 385V. 22X35
C804
!
0240136135 Ceramic 1000 pF. 20% 4KV
C806 0250210861 Electrolytic 0,47 µF. 50V.
C807 0270140338 Polyester 2200 pF. 10% 63V.
C809 0230300204 Ceramic SMD 330 pF. 10% 50V. 0805
C810 0230360406 Ceramic SMD 1000 pF. 10% 50V. 0805
C811 0250412962 Electrolytic 47 µF. 50V.
C812 0230240327 Ceramic SMD 100 pF. 5% 50V. 0805
C813 0270100431 Polyester 1000 pF. 10% 63V.
C850 0250465002 Electrolytic. 100µF. 160V. 16X25
C851 0250572468 Electrolytic 1000 µF. 16V.
C852 0240470708 Ceramic 220 pF. 5% 1KV. PULSE SL
C853 0270140338 Polyester 2200 pF. 10% 63V.
C854 0230360406 Ceramic SMD 1000 pF. 10% 50V. 0805
C856 0230600603 Ceramic SMD 100 nF. +80-20% 25V.
C857 0250320769 Electrolytic 10 µF. 16V.
C858 0250461266 Electrolytic 100 µF. 16V.
C859 0230640401 Ceramic SMD 220 nF. 10% 16V. 0805
C860 0230480600 Ceramic SMD 10 nF. +80-20% 50V 0805
C900 0230320301 Ceramic SMD 470 pF. 10% 50V. 0805
C901
!
0230240327 Ceramic SMD 100 pF. 5% 50V. 0805
C902 0250320769 Electrolytic 10 µF. 16V.
C903 0250410867 Electrolytic 47 µF. 16V.
C904 0230320301 Ceramic SMD 470 pF. 10% 50V. 0805
C905 0230320301 Ceramic SMD 470 pF. 10% 50V. 0805
C906 0230320301 Ceramic SMD 470 pF. 10% 50V. 0805
C909
!
0230320301 Ceramic SMD 470 pF. 10% 50V. 0805
C910 0250414307 Electrolytic N.P. 47 µF 20% 10V
C911 0250414307 Electrolytic N.P. 47 µF 20% 10V
C912 0250414307 Electrolytic N.P. 47 µF 20% 10V
C1400 AS2-F 0230360406 Ceramic SMD 1000 PF.10% 50V.
C1401 AS2-F 0230600603 Ceramic SMD 100 NF.+80-20% 25V.
C1402 AS2-F 0250320769 Electrolytic 10 µF. 16V.
C1403 AS2-F 0230480600 Ceramic SMD 10 NF. +80-20% 50V.
C1404 AS2-F 0250280864 Electrolytic 4,7 µF. 25V.
C1405 AS2-F 0250280864 Electrolytic 4,7 µF. 25V.
C1406 AS2-F 0230600603 Ceramic SMD 100 nF.+80-20% 25V.
C1407 AS2-F 0230360406 Ceramic SMD 1000 pF.10% 50V.
C1408 AS2-F 0230740003 Ceramic SMD 2,2 µF. 10V. +80-20%
C1409 AS2-F 0230740003 Ceramic SMD 2,2 µF. 10V. +80-20%
C1410 AS2-F 0230740003 Ceramic SMD 2,2 µF. 10V. +80-20%
C1411 AS2-F 0230360406 Ceramic SMD 1000 pF.10% 50V.
C1412 AS2-F 0230740003 Ceramic SMD 2,2 µF. 10V. +80-20%
C1413 AS2-F 0230740003 Ceramic SMD 2,2 µF. 10V. +80-20%
DIODES
D100 0360126304 Red 3mm.
D102 0360130819 1N 4148
D103 0790701106 R.M.G. SMD 0 Ω 1/10W. 0805
D104 0360130819 1N 4148
D105 0360130819 1N 4148
D106 0360130819 1N 4148
D107 0360111009 BAT 42 DO 35
D108 0360111009 BAT 42 DO 35
D109 0360111009 BAT 42 DO 35
D200 A2-C 0790701106 R.M.G. SMD 0 Ω 1/10W. 0805
D200 AS2-F 0790701106 R.M.G. SMD 0 Ω 1/10W. 0805
D200 A2-E 0360601512 SMD LS4148
D201 A2-E 0360601512 SMD LS4148
D250 0360706014 HZT33-02 RE
D251 AS2-F 0360601512 SMD LS4148
D302 0360601512 SMD LS4148
D303 0360601512 SMD LS4148
D400 0360601512 SMD LS4148
D600 0360601512 SMD LS4148
D601 0360601512 SMD LS4148
D606 0360601512 SMD LS4148
D607 0360601512 SMD LS4148
D611 0360601512 SMD LS4148
D651 0360601512 SMD LS4148
D652 0360601512 SMD LS4148
D661 0360377006 ERB44-04
D662 0360378400 ERB06-13
D663 0360377006 ERB44-04
D674 0360602411 Zener SMD BZT55C6V2
D675 0360601512 SMD LS4148
D680 0360377006 ERB44-04
D681 0360377006 ERB44-04
D685 0360601512 SMD LS4148
D700 0360601512 SMD LS4148
D701 0360130629 1N 4007 RL
D703 0360005409 Zener BZX79C24
D800 0360130629 1N 4007 RL
D801 0360130629 1N 4007 RL
D802 0360130629 1N 4007 RL
D803 0360130629 1N 4007 RL
D804 0360601512 SMD LS4148
D806 0360376909 ERB44-02
D850 0360376404 ERB44-06
D851 0360377303 Schottky ERB84-009 90V 2A
D852 0360601512 SMD LS4148
D901 0360602213 Zener SMD BZT55C5V1
D902 0360602213 Zener SMD BZT55C5V1
D904 0360602213 Zener SMD BZT55C5V1
D905 0360602213 Zener SMD BZT55C5V1
D906 0360602213 Zener SMD BZT55C5V1
D907 0360602213 Zener SMD BZT55C5V1
D908 0360602213 Zener SMD BZT55C5V1
D1200 AS2-F 0360601512 SMD LS4148
D1201 AS2-F 0360601512 SMD LS4148
FUSES
F-800 0760100701 Fuse Terminal Taped
F800
0330110503 Fuse T 2 A./250V. TIME-LAG
CONNECTORS
FB 0330144007 Ribbon Wire Holder 2 P.
FC 0330270307 2P. Socket
FE 0330115106 2P. Socket X RTM 1/6/8
FF 0330129701 4 P. Socket
FG 0330144205 Ribbon Wire Holder 4 P.
FI 0330163304 Ribbon Wire Holder 8 P.
INTEGRATED CIRCUITS
IC100A 0360516702 ST92185B1B1
