Sanyo CE14A2-C User Manual

Service Manual SM CE14A2-C
Ref. No. Part No. Description Ref. No. Part No. Description
9
IC125 0360711501 M24C04-MN6T
IC300 0360512305 TDA 7233 S
IC400 A2-C 0360514509 TDA 8841 N2
IC400 A2-E 0360514509 TDA 8841 N2
IC400 AS2-F 0360515001 TDA 8842 N2
IC701 0360516207 LA7840L
IC800 0360467203 MC44603P
IC850 0360472906 KA7805TU
IC1400 AS2-F 0360514806 SMD TDA9830T V1
IC1401 AS2-F 0360148209 SMD HEF 4052BT
JO400 A2-C 0790701106 R.M.G. SMD 0 Ω 1/10W. 0805
JO400 A2-E 0790701106 R.M.G. SMD 0 Ω 1/10W. 0805
JO401 A2-C 0790701106 R.M.G. SMD 0 Ω 1/10W. 0805
JO401 A2-E 0790701106 R.M.G. SMD 0 Ω 1/10W. 0805
JO652 0470040007 Jumper Lead 0,6 mm.
J139 0790701106 R.M.G. SMD 0 Ω 1/10W. 0805
J148 0790701106 R.M.G. SMD 0 Ω 1/10W. 0805
J149 0790701106 R.M.G. SMD 0 Ω 1/10W. 0805
J224 AS2-F 0470040007 Puente
J235 AS2-F 0470040007 Puente
J241 AS2-F 0470040007 Puente
J242 AS2-F 0470040007 Puente
J243 AS2-F 0470040007 Puente
J246 AS2-F 0470040007 Puente
J251 AS2-F 0470040007 Puente
J297 AS2-F 0470040007 Puente
J300 AS2-F 0790701106 R.M.G. SMD 0 OHM 1/10W.
J306 AS2-F 0790701106 R.M.G. SMD 0 OHM 1/10W.
J343 AS2-F 0470040007 Puente
J301 A2-C 0470040007 Jumper Lead 0,6 mm.
J301 AS2-F 0470040007 Jumper Lead 0,6 mm.
J342 0790701106 R.M.G. SMD 0 Ω 1/10W. 0805
J383 0790701106 R.M.G. SMD 0 Ω 1/10W. 0805
J385 0790701106 R.M.G. SMD 0 Ω 1/10W. 0805
J389 0790701106 R.M.G. SMD 0 Ω 1/10W. 0805
J392 0790701106 R.M.G. SMD 0 Ω 1/10W. 0805
J400 0790701106 R.M.G. SMD 0 Ω 1/10W. 0805
J503 0790701106 R.M.G. SMD 0 Ω 1/10W. 0805
JC0 AS2-F 0790701106 R.M.G. SMD 0 OHM 1/10W.
JC4 AS2-F 0790701106 R.M.G. SMD 0 OHM 1/10W.
JC5 AS2-F 0790701106 R.M.G. SMD 0 OHM 1/10W.
JC6 A2-E 0790701106 R.M.G. SMD 0 OHM 1/10W.
JC8 AS2-F 0790701106 R.M.G. SMD 0 OHM 1/10W.
JO1151 AS2-F 0790701106 R.M.G. SMD 0 OHM 1/10W.
COILS
L100 0470040007 Jumper Lead 0,6 mm.
L101 0470040007 Jumper Lead 0,6 mm.
L102 0090317223 Peaking Coil 100 µH. 10%
L103 0090305525 Choke R.F. 33 µH. 10%
L201 A2-C 0090319328 Peaking Coil 15 µH. 10%
L201 A2-E 0090315029 Choque R.F. 10 µH. 10%
L201 AS2-F 0090315029 Choque R.F. 10 µH. 10%
L250 A2-C 0090319229 Peaking Coil 4,7 µH. 10%
L251 A2-C 0090316845 Peaking Coil 1µH 10% RADIAL
L251 AS2-F 0090317140 Choque R.F. 0,39 µH. 20% Radial
L252 AS2-F 0090316845 Choque R.F. 1µH 10% Radial
L300
0790528814 Fuse 2,2 Ω 5% 0,33W.
L301 0470040007 Jumper Lead 0,6 mm.
L304 0090305327 Peaking Coil 10 µH. 10%
L400 0090319229 Peaking Coil 4,7 µH. 10%
L401 0090319229 Peaking Coil 4,7 µH. 10%
L402 0090319229 Peaking Coil 4,7 µH. 10%
L403 0090319229 Peaking Coil 4,7 µH. 10%
L404 0790701106 R.M.G. SMD 0 Ω 1/10W. 0805
L405 0090319229 Peaking Coil 4,7 µH. 10%
L600 0470040007 Jumper Lead 0,6 mm.
L666 0470040007 Jumper Lead 0,6 mm.
L701 0470040007 Jumper Lead 0,6 mm.
L702 0470040007 Jumper Lead 0,6 mm.
L800
!
0090413709 Mains Filter 2X19 MH. 250 VAC. 0,5A
L801 0090318668 Peaking Coil 1 µH. 20% I MAX=270MA
L802 0470040007 Jumper Lead 0,6 mm.
L850 0620005504 Ferritebead 3,5X6 80 Ω/100 MHz
L851 0620005504 Ferritebead 3,5X6 80 Ω/100 MHz
L853 0620005504 Ferritebead 3,5X6 80 Ω/100 MHz
L900 0620011502 Ferrite SMD 0603 600 Ω/20 MHz
L901
!
0090315029 Peaking Coil 10 µH. 10%
L902
!
0090316845 Peaking Coil 1µH 10% RADIAL
L903
!
0090318668 Peaking Coil 1 µH. 20% I MAX=270MA
L1401 AS2-F 0090319229 Choque R.F. 4,7 µH. 10%
PCB11
0750152514 MAIN PCB EC7-A
BUTTON
PL100 0130214703 PUSH Switch Insertable 160GR.
PL101 0130214703 PUSH Switch Insertable 160GR.
PL102 0130214703 PUSH Switch Insertable 160GR.
PL103 0130214703 PUSH Switch Insertable 160GR.
PTC800
0810101907 P.T.C. 18 Ω
TRANSISTORS
Q101 0360308803 SMD PMBT2369
Q102 0360320501 BRT SMD PDTA124ET
Q104 0360321301 SMD BC 857 B
Q200 0360320303 SMD BC 847 B
Q201 0360321301 SMD BC 857 B
Q250 AS2-F 0360320303 SMD BC 847 B
Q251 0360308803 SMD PMBT2369
Q252 0360320501 BRT SMD PDTA124ET
Q253 0360320501 BRT SMD PDTA124ET
Q254 0360320501 BRT SMD PDTA124ET
Q401 0360321301 SMD BC 857 B
Q402 0360320303 SMD BC 847 B
Q600 0360308704 KSP 44 TO-92
Q601 0360321301 SMD BC 857 B
Q611 0360320600 BRT SMD PDTC124ET
Q650 0360308902 2SD2599
Q651 0360320303 SMD BC 847 B
Q673 0360320303 SMD BC 847 B
Q800 0360311005 MOS 2SK3067 600V/2A
Q850 0360320303 SMD BC 847 B
Q851 0360308605 KSP 92 TO-92
Q852 0360308506 KSP 42 TO-92
Q853 0360306104 2SB 764 E
Q853 AS2-F 0360173504 TIP 32 C
Q854 0360320303 SMD BC 847 B
Q855 0360320303 SMD BC 847 B
Q856 0360169718 BC 639
Q857 0360321301 SMD BC 857 B
Q858 0360321301 SMD BC 857 B
Q859 0360321301 SMD BC 857 B
Q860 0360321301 SMD BC 857 B
Q900 0360320303 SMD BC 847 B
Q1200 AS2-F 0360320303 SMD BC 847 B
Q1201 AS2-F 0360320303 SMD BC 847 B
Q1400 AS2-F 0360320410 SMD BF 570
Q1401 AS2-F 0360320600 BRT SMD PDTC124ET
Q1404 AS2-F 0360320303 SMD BC 847 B
RI100 0600123004 Infrared Receiver TSOP1838
RESISTORS
R100 0790242002 R.M.G. SMD 1,8 KΩ 5% 1/10W. 0805
R101 0790251003 R.M.G. SMD 10 KΩ T<=5% 0805
R102 0790251003 R.M.G. SMD 10 KΩ T<=5% 0805
R104 0790245005 R.M.G. SMD 3,3 KΩ T<=5% 0805
R105 0790752208 R.M.G. SMD 12 KΩ T<=5% 0805
R106 0790753909 R.M.G. SMD 15 KΩ T<=5% 0805
R108 0790138804 Carbon 1 KΩ 5% 1/6W.
R110 0790248009 R.M.G. SMD 5,6 KΩ T<=5% 0805
R111 0790235006 R.M.G. SMD 470 Ω T<=5% 0805
R112 0790126700 Carbon 100 Ω 5% 1/6W.
R113 0790159503 Carbon 47 KΩ 5% 1/6W
R115 0790251409 R.M.G. SMD 12 KΩ 1% 1/10W.
R116 0790255103 R.M.G. SMD 22 KΩ 1% 1/10W.
R117 0790368922 Metal Film 4,70 KΩ 1% 0,4W.
R118 0790126700 Carbon 100 Ω 5% 1/6W.
R119 0790251003 R.M.G. SMD 10 KΩ T<=5% 0805
R120 0790248108 R.M.G. SMD 5,6 KΩ 1% 1/10W.
R121 0790251003 R.M.G. SMD 10 KΩ T<=5% 0805
R123 0790248009 R.M.G. SMD 5,6 KΩ T<=5% 0805

Sanyo CE14A2-C Specifications

General

Brand	Sanyo
Model	CE14A2-C
Category	TV
Language	English
